Specification
|
| X-ray generator |
Max. 350W~500W |
| Detector |
367mm / 585mm |
| 65mm |
| Conveyor |
10~35M / M |
| 420mm / 620mm |
| 12kg / 15kg |
| Tower lamp |
3 colors |
| Control Computer |
Industrial computer |
| Monitor |
15" Touch screen |
| Interface |
Possible to store at USB port |
| Product register |
Possible to register max. 10,000 models |
| Masking function |
Image of product, function of brightness (16 kinds) |
| Product management |
Daily / Month / Model product capacity analysis |
| Equipment management |
MTBF, MTTR, Error log, Error analysis |
| Teaching |
Auto searching, Manual teaching (Deep-learning optional) |
| Image management |
Image Save / Analysis (Defect size measurement) |
| Protection class |
IP66 grade (High water protection & SS316 frame optional) |
| Washing |
Easy to clean |
| X-ray leakage |
Maximum 1 μSv / h or less |
| Power requirements |
AC220V, 50 / 60 Hz, 1.2 kVA |
| Weight |
Approx. 525kg / 790kg |
| Temperature |
5°C~35°C |
